Twin Ceiling Mount 12000 - Ductless (220V Condenser) Wine Cooling Unit

$19,119.00

High-capacity twin evaporator split system for cellars up to ~4,600 ft³. Discreet, ultra-quiet, and precise bottle-probe control with 220 V H.E. condenser.


Cooling Capacity: 9292 BTU/H


Let Us Help

Not sure which product is right for you? Reach out and we'd be happy to help. Contact Us

Cooling Calculator

Input your project details our handy calculator to figure out what type of cooling system you need. Try The Calculator


The WhisperKOOL Twin Ceiling Mount 12000 is a powerful, ductless split cooling system featuring dual ceiling-mounted evaporators and a high-efficiency 220 V outdoor condenser. Engineered for large wine cellars up to 3,000 – 4,600 ft³, it offers hidden installation with balanced airflow and precise control via WhisperKOOL’s liquid-temperature bottle probe—ideal for high-end collections and dedicated wine environments

Twin Ceiling Mount 12000 - Ductless (220V Condenser) Wine Cooling Unit

$19,119.00
Features

Dual ceiling-mounted evaporator units for even, hidden airflow

High-efficiency 220 V condenser optimized for performance and energy savings

Designed for cellars from 3,000 to 4,600 ft³ depending on insulation and heat load

KDT digital controller with liquid-temperature bottle probe for true cellar conditions

Flare fittings eliminate on-site brazing; line sets up to 100 ft

e-coated Duramax coils and hex-mesh grille with washable filter

Bottom-access wiring and diagnostics port for simplified servicing

Two-speed fan switch for airflow customization

Maintains 55 °F cellar temperature even with condenser intake temps up to 120 °F

Specs

Cooling Capacity:

~8,951 BTU/hr (60 °F intake), ~9,292 BTU/hr (75 °F), ~9,079 BTU/hr (85 °F)

Coverage Volume: 3,000 to 4,600 ft³ (well-insulated)

Evaporator Dimensions (each): 35.75″ L × 14.5″ W × 12.75″ H — Weight: 66 lb

Condenser Dimensions: 31.18″ L × 10.75″ W × 23.25″ H — Weight: 84 lb

Electrical Requirements:

Evap units: 120 V / 15 A each

Condenser: 220 V / 15 A

Refrigerant: R-134a

Line Set: Liquid 3/8″ OD; Suction 5/8″ (<50 ft) or 3/4″ (>50 ft)

Drain Line: 1/4″ ID clear tubing (rigid recommended)
