Mini Ceiling Mount - Ductless (110V Condenser) Wine Cooling Unit

$10,563.00

Compact ceiling-mounted split system for cellars up to ~500 ft³. Nearly invisible installation, ultra-quiet, and precise temperature control using bottle probe technology.


Cooling Capacity: 3000 BTU/H


Let Us Help

Not sure which product is right for you? Reach out and we'd be happy to help. Contact Us

Cooling Calculator

Input your project details our handy calculator to figure out what type of cooling system you need. Try The Calculator


The WhisperKOOL Mini Ceiling Mount (HE) is a ductless split system designed for discreet installation within the cellar ceiling, providing quiet and efficient cooling without occupying valuable wall space. This high-efficiency system is ideal for cellars up to approximately 500 ft³, depending on insulation and heat load. Equipped with a liquid-temperature-measuring bottle probe and advanced digital display, the Mini Ceiling Mount delivers precise, consistent temperature control while remaining nearly invisible in the cellar.

Mini Ceiling Mount - Ductless (110V Condenser) Wine Cooling Unit

$10,563.00
Features

Fully ductless split system design; evaporator mounted flush in cellar ceiling

Cooling capacity to maintain 55 °F in cellars up to ~500 ft³ (depending on insulation and ambient conditions)

Ultra-quiet operation with minimal vibration

High-efficiency condenser (air-cooled), up to 100 ft line set length supported

Liquid-temperature-measuring bottle probe for highly accurate control

Advanced KDT digital controller with wall or flush mount display options

Integrated condensate pump system to manage drainage

Black finish with paintable grille and mounting bracket for custom aesthetics

Washable return air filter for easy maintenance

24V thermostat control option supported

Specs

Cooling Capacity (approx.): 2,000 – 3,000 BTU/hr (varies by ambient condenser temp)

Recommended Coverage: Up to ~500 ft³

Temperature Range: Adjustable setpoint 50–70 °F

Evaporator Dimensions: 25.05″ L × 11.34″ W × 11.17″ H

Condenser Dimensions: 31.18″ L × 10.75″ W × 21.18″ H

Refrigerant: R-134a

Electrical: Evaporator: 120 V, 15 A dedicated circuit; Condenser: 220 V, 15 A dedicated circuit

Weight: Evaporator ~35 lb; Condenser ~51 lb

Line Set: Liquid line 1/4″ OD; suction line 3/8″ OD (<50 ft) or 1/2″ OD (>50 ft)

Drain Line: 1/4″ ID clear plastic tubing (rigid line recommended)
