Ceiling Mount 8000 - Ductless (110V Condenser) Wine Cooling Unit

Ductless split system with flush ceiling-mounted evaporator

Cooling capacity to maintain 55 °F in cellars up to ~1,750 ft³ (varies by insulation and ambient conditions)

High-efficiency outdoor air-cooled condenser

Advanced digital KDT controller with liquid-temperature bottle probe

Quiet, vibration-minimized operation; ideal for luxury residential installations

Supports line set lengths up to 100 ft

Built-in condensate management system (requires drain line)

Flexible 24V thermostat integration (customer-supplied option)

Two-speed fan for airflow optimization

Black paintable grille for design flexibility

Includes mounting hardware and vibration isolators

Cooling Capacity: Approx. 5,000 – 6,000 BTU/hr (varies by ambient condenser temp)

Recommended Coverage: Up to ~1,750 ft³

Temperature Range: Adjustable setpoint 50–70 °F

Evaporator Dimensions: 51″ L × 31″ W × 17.5″ H (with vibration isolators and drip tray)

Condenser Dimensions: 31.18″ L × 10.75″ W × 21.18″ H

Refrigerant: R-134a

Electrical:

Evaporator: 120 V / 15 A dedicated circuit

Condenser: 220 V / 15 A dedicated circuit

Weight: Evaporator ~56 lb; Condenser ~56 lb

Line Set: Liquid line 1/4″ OD; suction line 1/2″ OD (<50 ft) or 5/8″ OD (>50 ft)

Drain Line: 1/2″ ID (clear tubing, not included)
